Abrites FN015 Engine Control Unit Configuration Manager for FCA

Abrites FN015 Engine Control Unit Configuration Manager for FCA-0 thumb
DG-ABR-FN015

Abrites FN015 Engine Control Unit Configuration Manager for FCA

$475.00

  • Digital Product
  • New Arrival
Abrites SKUFN015
BrandAbrites
Product typeSoftware licence
FunctionECU configuration data read / update, calibration, make virgin
Vehicle makesFiat, Lancia, Alfa Romeo
FitsJTD and 1.3 MultiJet models with Bosch EDC15C5 / EDC15C7 / ME7.3 and Marelli IAW / MJD ECUs
Working methodOBD; boot mode where OBD is not possible
RequiresAVDI interface with active annual subscription (AMS)
AvailabilityDelivered electronically

The Abrites FN015 licence is dedicated to reading and updating the internal configuration memory of engine control units in Fiat, Lancia, Alfa Romeo and other FCA (Fiat Chrysler Automobiles) vehicles by OBD. It is the licence to have when an ECU has to be replaced, matched to another car or returned to a virgin state.

Functionalities

  • Read and update ConfData by OBD
  • Calibration by OBD
  • Make virgin by OBD

Where a unit cannot be worked on by OBD, boot mode is required.

Supported units

  • Bosch: EDC15C5 EURO2, EDC15C7 EURO3, ME7.3H4 (boot mode), ME7.3.1 (boot mode)
  • Marelli: IAW 4AF, IAW 4EF, IAW 59F, IAW 59M, IAW 5AF (HW30x, ST10F168), IAW 5AF (HW60x, ST10F269), IAW 5AM, IAW 5NF, IAW 5SF3/5SF8 (K-line), IAW 5SF3 (CAN), IAW 5SF8 (CAN), IAW 5SF9 (CAN), 8GMF, 8GMK, 8GSF, 8GSW/8GMW, 9GF, MJD 6JF (K-line), MJD 6F3 (K-line), MJD 6F3 (CAN), MJD 8F2 (K-line), MJD 8F2 (CAN), MJD 8F3 (CAN), MJD 9DF

Supported models include

  • Alfa Romeo: 145 1.9 JTD, 146 1.9 JTD, 147 1.9 JTD 8V and 16V, 156 1.9 JTD and 2.4 JTD, 166 2.4 JTD and others
  • Fiat: Bravo, Brava, Doblo, Marea, Marengo, Punto, Palio, Stilo and Siena 1.9 JTD, Marea 2.4 JTD, Ducato 2.0 / 2.3 JTD, Scudo 2.0 JTD and others
  • Fiat with 1.3 MultiJet (IAW MJD 6JF): New Panda, Idea, Doblo, Punto, Grande Punto, Cinquecento
  • Lancia: K 1.9 JTD, Lybra 1.9 and 2.4 JTD, Thesis 2.4 JTD, Z 1.9 JTD and others; Musa and Ypsilon with the 1.3 MultiJet

An AVDI interface with an active annual subscription is required to use this licence. Delivered electronically; your AVDI serial number is needed to process the order.
