Abrites SB003 Key Programming by RH850 Dump and ESL Reset for Subaru
| Abrites SKU | SB003 |
| Brand | Abrites |
| Product type | Software licence |
| Function | Key programming with faulty ESL; ESL reset and sync |
| Vehicle makes | Subaru |
| Fits | All keyless Subaru vehicles 2020+ |
| Working method | By RH850 dump of the Smart system, on bench |
| Requires | AVDI interface with active annual subscription (AMS) |
| Additional hardware | ZN085 RH850/V850 programmer with CB501, TA68 emulator, ZN103 PROTAG, CB012 (ESL replacement) |
| Availability | Delivered electronically |
Abrites / Software - Token
The Abrites SB003 licence allows working on Subaru vehicles with faulty ESL modules for key programming in all keys lost situations. With it you can get the data from the Smart system, replace the ESL with a new or a used one, and program a smart key to the vehicle.
Functionalities
- Smart system data flash reading and programming new keys to the vehicle
- Reset and synchronise a second-hand ESL module with the Smart system
- Synchronise a new virgin ESL with the Smart system
How the procedure runs
- Take the Smart system out of the vehicle and read its data flash on bench with the ZN085 RH850/V850 programmer
- Use the dump to prepare a TA68 (DST-AES) emulator for the Smart system
- With the TA68 emulator, synchronise the Smart system with the new virgin ESL — or with a second-hand ESL module
- After syncing, learn new keys with the PROTAG programmer
Supported vehicles: all keyless Subaru vehicles 2020+.
Required hardware
- ZN085 Abrites RH850/V850 programmer and the CB501 cable included in its set — for reading the data flash on bench
- TA68 DST-AES transponder emulator — for ESL and Smart system sync
- PROTAG key and transponder programmer — to program new keys
- CB012 cable set — required in case of ESL replacement
An AVDI interface with an active annual subscription is required to use this licence. Delivered electronically; your AVDI serial number is needed to process the order.
