Abrites TN022 Dashboard Calibration for Toyota and Lexus
| Abrites SKU | TN022 |
| Brand | Abrites |
| Product type | Software licence |
| Function | Instrument cluster calibration |
| Vehicle makes | Toyota, Lexus |
| Fits | Clusters with S6J3 MCU (Camry 2018+, Corolla 2019+, RAV4 2019+, Yaris 2018+, Lexus LS); RH850 digital clusters (Tundra 2023+, Corolla 2023 and more, up to 2025) |
| Working method | OBD or internal CAN bus |
| Requires | AVDI interface with active annual subscription (AMS) |
| Additional hardware | CB012 cable set, CB031 extension cable |
| Availability | Delivered electronically |
Abrites / Software - Token
The Abrites TN022 licence allows quick instrument cluster calibration in Toyota and Lexus vehicles. There is no need to open the module — all work is performed via the OBD or internal CAN bus connection.
Functionality
- Calibration of LOCKED and UNLOCKED instrument clusters using S6J3 microcontrollers
- Cluster calibration for fully digital Denso instrument clusters with RH850 processors (no crypto core)
Supported vehicles
- Latest: Toyota Tundra 2023+ with fully digital instrument cluster
- All Toyota and Lexus vehicles with S6J3 microcontrollers, such as Toyota Camry 2018+, Corolla 2019+, RAV4 2019+, Yaris 2018+ and Lexus LS
- Toyota and Lexus vehicles with RH850 processors, such as Toyota Corolla 2023, Corolla Cross 2023 and Lexus LS 500 2023
- Other models up to 2025 with fully digital instrument clusters (without analogue gauges or LED indicators) equipped with RH850 processors (no crypto core)
Legal notice. This product is intended solely for lawful purposes, such as restoring the correct mileage after instrument cluster repair or replacement. Altering an odometer reading with intent to misrepresent a vehicle's actual mileage is a federal offence under 49 U.S.C. § 32703. The user is solely responsible for compliance with all applicable federal and state laws, including odometer disclosure requirements.
What you need alongside it. Abrites lists the CB012 direct CAN-BUS / LIN-BUS cable set and the CB031 extension cable for the Toyota / Lexus Smart System (B9 / BA) as the hardware needed to complete all procedures.
An AVDI interface with an active annual subscription is required to use this licence. Delivered electronically; your AVDI serial number is needed to process the order.
