Abrites MN037 Cluster Calibration IC177 for Mercedes-Benz
| Abrites SKU | MN037 |
| Brand | Abrites |
| Product type | Software licence |
| Function | IC177 cluster calibration, virgin and adapt, clear ASSIST+ |
| Vehicle makes | Mercedes-Benz |
| Fits | IC177 2018–2023 (Visteon R7F701403): W177, W247, H243 EQA, X243 EQB, C118, H247, W167, W213 FL, W238, X247, W257, X290, R232 |
| Working method | On bench — soldering required |
| Requires | AVDI interface with active annual subscription (AMS) |
| Additional hardware | ZN085 RH850/V850 programmer with CB501, ZN092 adapter |
| Availability | Delivered electronically |
Abrites / Software - Token
The Abrites MN037 licence gives you the ability to calibrate IC177 clusters in Mercedes-Benz vehicles up to 2023. It does not affect the EZS module, which makes it much safer and easier to use — the EZS is not even needed during the procedure, because all the work is done on the IC177 cluster itself.
Functionality
- Adjust the value stored in the IC177 dashboard
- Block the synchronisation of the dashboard with the EZS module
- Set the dashboard to virgin state and adapt
- Clear ASSIST+ information
The procedure requires working on the IC177 module's PCB on bench: unsoldering a few capacitors and soldering the wires of the CB501 cable onto it. Wiring diagrams are available in the software.
Supported vehicles
Mercedes-Benz vehicles equipped with the IC177 2018–2023 (Visteon R7F701403), such as:
- W177 A-Class
- W243 and W247 B-Class
- H243 EQA
- X243 EQB
- C118 CLA
- H247 GLA
- W167 GLE / GLS
- W213 E-Class facelift
- W238 E-Class Coupe
- X247 GLB
- W257 CLS
- X290 AMG GT Four Door facelift
- R232 SL 2022+
- Other models with the IC177 equipped with Visteon R7F701403
Required hardware
- ZN085 RH850/V850 programmer with its CB501 connection cable
- ZN092 adapter for the ZN085 (5V to 3.3V)
This licence is intended for lawful repair work — restoring the correct reading after a cluster has been repaired or replaced.
An AVDI interface with an active annual subscription is required to use this licence. Delivered electronically; your AVDI serial number is needed to process the order.
