Abrites TN017 ID Code Box Reset and Adaptation for Toyota and Lexus

Abrites TN017 ID Code Box Reset and Adaptation for Toyota and Lexus-0 thumb
DG-ABR-TN017

Abrites TN017 ID Code Box Reset and Adaptation for Toyota and Lexus

$710.00

  • Digital Product
  • New Arrival
Abrites SKUTN017
BrandAbrites
Product typeSoftware licence
FunctionID Code Box reset and adaptation
Vehicle makesToyota, Lexus
FitsAll Toyota and Lexus models up to and including 2024
Working methodLIN bus reset; OBD or internal CAN adaptation
RequiresAVDI interface with active annual subscription (AMS)
Additional hardwareCB012 cable set, CB031 extension cable
AvailabilityDelivered electronically

The Abrites TN017 licence allows you to reset and adapt the ID Code Box of all Toyota and Lexus models up to and including the 2024 model year. Because of where the module sits, removing it normally means extensive disassembly — this licence eliminates much of that work.

Functionality

  • ID Code Box reset (via LIN bus)
  • ID Code Box adaptation in the vehicle (new or reset second-hand module) to the Smart System via OBD (up to 2024)
  • ID Code Box adaptation in the vehicle to the Smart System via internal CAN bus (2024)
  • ID Code Box adaptation in the vehicle to the engine control unit (ECU) via OBD

New: replace the ID Code Box, Smart System, ECU and hybrid modules in the latest Toyota and Lexus vehicles equipped with B6 smart keys.

When it is needed

Resetting the ID Code Box is required whenever the ID Code Box itself, the Smart System and / or the ECU needs to be replaced. Replacing the Smart System requires pairing it with the ID Code Box, and pairing is only possible after the ID Code Box has been reset; the same applies to the ECU. When exchanging the Smart System or ECU there is no need to remove the ID Code Box from the vehicle, and the reset is quick whether or not the vehicle has an ESL (Electronic Steering Lock) module.

When a virgin ID Code Box is installed, it must be synchronised with the ECU and Smart System, and a working key is required. TN017 performs this synchronisation via the OBD-II port.

Supported vehicles: all Toyota and Lexus models up to and including 2024.

What you need alongside it. Abrites lists the CB012 direct CAN-BUS / LIN-BUS cable set and the CB031 extension cable for the Toyota / Lexus Smart System (B9 / BA) as the hardware needed to complete all procedures.

An AVDI interface with an active annual subscription is required to use this licence. Delivered electronically; your AVDI serial number is needed to process the order.
